Food Grade Silicone Gaskets Sea BPA Free Seals Rings for Leak Proof 25kN/M

Large Image : Food Grade Silicone Gaskets Sea BPA Free Seals Rings for Leak Proof 25kN/M

Product Details:

Place of Origin:	China
Brand Name:	Tenchy
Certification:	FDA, LFGB, UL, ROSH, SGS
Model Number:	TS-FSG02

Payment & Shipping Terms:

Minimum Order Quantity:	10000 pcs
Packaging Details:	Opp plastic bags and Standard carton.
Delivery Time:	5-10 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50,000pcs per day

Contact Now

Detailed Product Description

Products:	Silicone Gasket	Brand:	TENCHY
Color:	Can Be Customized	Model No:	TS-FSG02
Material:	100% Pure Silicone Raw Material	Certifications:	RoHs, Reach, FDA, LFGB
Size:	Can Be Customized	OEM:	OEM Service Available
High Light:	25kN/m Silicone Seal Gasket , 25kN/m food grade rubber seal , FDA OEM food grade rubber seal

Food grade Air Tight Container Silicone Rubber Gasket

Features

Product Name	Silicone Seal Gaskets
Material	100% Silicone
Processing Method	Press Moulding
Feature	Water-proof, Ageing Resistant
Tolerance	± 0.05 mm
Quality Standards	RoHs, LFGB
Application	Mechanical, construction, or special purpose
Product Safety	Oil resistance, no smell

Descriptions

Silicone Rubber has been designed primarily for use as sealing gasket, food grade or Heat resistant strip, and is mainly

used for long term sealing applications, which incur a unlimited number of compressions during service. Its properties make

it suitable for use in a wide range of applications including:

> Insulation barriers

> Variety of long term sealing applications

> Gaskets and seals

Technical Information

Polymer	Silicone Rubber
Color	Natural, Black, White, Rust Red and other color
Density	1.14g/cm³
Hardness	30-90 Shore A
Tensile Strength	>9.5Mpa
Elongation @ Breakage	>550%
Tear Strength	25kN/m
Linear Shrinkage	3.3-3.7
Rebound Resiliance	>50%
Temperature Range	-40°C to +200°C
For 300℃ Temperature Resistant Special Silicone is Available

Food Grade Silicone Gaskets Sea BPA Free Seals Rings for Leak Proof 25kN/M 0

Food Grade Silicone Gaskets Sea BPA Free Seals Rings for Leak Proof 25kN/M 1

Food Grade Silicone Gaskets Sea BPA Free Seals Rings for Leak Proof 25kN/M 2

Low Pressure Sealing

In a low pressure sealing application, the system pressure is too low to “activate” the seal. The design must rely solely on the resilience of the elastomer to retain the needed sealing force. Proper seal material selection and surface finish on both the seal and gland are critical to an effective seal

High Pressure Sealing

In high pressure sealing applications, the system pressure does “activate” the seal to fill potential leak paths. Attention does need to be given to seal material hardness and hardware clearances to prevent potential seal extrusion.
